Model | A627.H8G |
Passenger capacity | 2 |
Overall dimension | L366.3 X W131 X H202.9 CM |
System | 48V 4KW AC system |
Battery | 8V-170AH*6pcs |
Motor | 48V/4KW AC Asynchronous Motor |
Controller | Toyota 48M350A-350A |
Tranaxle | with 16:1 gear ratio |
Range (loaded) | 60-80 km |
Max. speed | 25 km/h |
Minimum turning radius | 4.9 m |
Safe climbing ability (loaded) | 10% |
Brake distance | 6 m |
Curb weight(including battery) | 585 kgs |
Min. ground clearance (mm) | 157 mm |
Tread (mm) | Front 982 mm / Rear 1000 mm |
Wheelbase (mm) | 2480 mm |
